DETAILS
Achieve perfect welds every time with exceptional versatility. This inverter delivers continuous, high-quality welding on unalloyed, low-alloy, and stainless steel materials.
Features
- Superior Welding Performance : Delivers consistent, high‑quality welds on unalloyed, low‑alloy, and stainless steels. Designed for rutile and especially basic electrodes in 2.5, 3.25, and 4.0 mm, ensuring smooth operation and clean, professional seams.
- Versatile & Compatible: Features the widely used 35–50 mm output connector for easy compatibility with most welding equipment—ideal for professionals seeking simplicity and performance.
- Easy Setup & Clear Control : A bright LED display and push‑button encoder make parameter adjustment fast and intuitive. Quickly select electrode sizes 2.5, 3.25, and 4.0 mm for maximum flexibility.
- Quick Arc Start and Control : HOT START boosts starting current in 10 steps for quick arc ignition. ARC FORCE fine‑tunes penetration in 10 steps, preventing electrode sticking and ensuring smoother welding.
- Safety & Compliance: Fully compliant with CE, EN 60974‑1, and EN 60974‑10 standards, with built‑in LVD and EMC protection for safe, worry‑free operation.
- Compact & Portable : Lightweight design with handle and shoulder strap for easy transport—perfect for mobile professionals who need reliable performance everywhere.
Service Information
Documentation
You May Also Need
Specifications
Weights & Dimensions
| Dimensions (H x W x D) | 260 mm x 170 mm x 320 mm |
| Net Weight | 4.5 kg |
Technical Specifications
| Machines Processes | Stick (SMAW) |
| Input Voltage | 230V |
| Input Current | 16A |
| Input Hertz | 50/60 Hz |
| Input Phase | 1ph |
| Input Power | 230/1/50-60 Hz (+/-15%) |
| Mode Icon | CC |
| Output Range | 10-200A |
| Polarity | DC |
