MOBIFLEX® 200M

MOBIFLEX® 200M – Mobile Filtration, Maximum Efficiency

Powerful dry fume extraction with high-capacity filtration—ideal for medium-duty and stainless steel welding.

LOW-VACUUM MOBILE FILTRATION UNITS

MOBIFLEX® 200 M is designed specially to extract and filter dry welding fumes from light or medium welding activities.

It is easy to use, and its high filtration capacity (50 m²) and efficiency give it a longer life.

- Maximum capture rate at the arm: 1,250 m³/h.
- Cassette type mechanical filter.
- Metal pre-filter - Class EU2.
- Filter surface area 50 m² - Class M.
- Cartridge saturation indicator.
- Motor 0.75 kW.
- Vertical air outlet.
- Noise: 69 dB(A).
- Complement: 3 or 4 m long LFA arm (not included).

MOBIFLEX® 200 M/W3 has IFA W3 certification according to standard EN 15021/1. It has high efficiency W3 filter included and it's ready for stainless steel welding fumes extraction.

MOBIFLEX® 200M Filter System

The LongLife filter in the Mobiflex® 200-M has a surface area of 50m2, making it one of the largest disposable filter cartridges in its class. The combination of filter size and unique 3D-pleated structure results in higher filter efficiency, longer filter life, and lower operational costs. A filter status indicator located on the front of the Mobiflex® 200-M gradually moves from white to red as the filter becomes saturated with particulate, providing visual indication of when system maintenance and filter replacement is necessary. A washable aluminum pre-filter removes larger-sized particulate and provides spark entrapment.
