DETAILS
Ultimate Portability. Unrivaled Performance.
Designed, built, and tested to deliver the industry’s leading battery powered welder, the ELEVATE™ SLi combines unlimited portability with the trusted, reliable arc performance you expect from Lincoln Electric. Engineered to withstand rugged jobsite conditions, this durable and lightweight system offers up a powerful cordless Stick & TIG welder that ELEVATEs your operator’s versatility on the jobsite.
Features
- Outstanding Arc Performance - Provides a powerful 145A output for highly efficient welding.
- Proven Chopper Technology - Ensures easy starts, a smooth arc, low spatter, and optimal bead appearance.
- Range of Welding Capabilities - Supports a wide range of welding rods, including 6010 and 7018 up to 5/32", and features Touch Start TIG functionality.
- Advance Features - Hot Start and Arc Force can be adjusted to improve electrode starting and control penetration profile.
- Incredible Portability - Designed for easy transportation, weighing only 33 lbs and featuring an adjustable shoulder strap for added convenience.
- Go Anywhere Sustainably - Easily maneuverable on job sites and does not require extra-long weld cables or a generator, making it an excellent option for remote work locations.
- Internal Rechargeable Battery - Employs Lithium Iron Phosphate technology to offer extended battery life, enabling the welding of up to electrodes on a single charge.
- All-in-One Internal Charging System - The integrated internal charging system can charge in 60 minutes using 120V input power, eliminating the need for an external charger.
- Built for Durability - Built to withstand challenging welding environments with an IP23S rating and fan as-needed circuitry, ensuring long-lasting performance
- Trusted Expertise & Support - Backed by a 3-year warranty from Lincoln Electric, providing peace of mind and reliable support for your investment.
Disclaimers
Service Information
What's Included
- (1) Elevate™ SLi Battery Powered Welder
Documentation
You May Also Need
Specifications
Machine Inputs & Outputs
| Phase 1: Input Voltage #1 (Voltage/Phase/Hertz) | 120/1/60 |
| Phase 1: Rated Output #1A (Current/Voltage/Duty Cycle) | Stick 145A/25.8V |
| Phase 1: Rated Output #1B (Current/Voltage/Duty Cycle) | TIG 145A/15.8V |
Product Weights & Dimensions
| Dimensions (H x W x D) | 14 in x 9.1 in x 18.3 in (356 mm x 231 mm x 465 mm) |
| Net Weight | 33 lbs (15 kg) |
General Specification
| Machines Processes | Stick (SMAW) TIG (GTAW) |
| Open Circuit Voltage | Average: 55V Peak: 72V |
| Number of Operators per Machine | 1 |
| Input Voltage | 120 |
| Input Hertz | 60 Hz |
| Input Phase | Single Phase |
| Mode Icon | CC |
| Output Range | Stick : 10-145A TIG 4-145A |
| Polarity | DC |
Machine Technologies & Connections
| IEC Rating | IP23S |
| Machines Communication Technology | analog |
| Work Lead Connector Type | Dinse |
Battery
| Battery Type | Lithium Iron Phosphate (LiFePO4) battery |
| Watt Hours (Wh) | 576 |
| Charge Time | 60 minutes |
Application
| Typical Application | Construction Mining Railroad Maintenance Automotive Brewery Construction & Field Erection General Fabrication Maintenance & Repair Marine Applications Marine Fabrication & Repair Offshore Repair Welding Shipbuilding Structural Fabrication |
Warranty
| Warranty | 3 Years |
